Farmtrac 450DTC

Last Updated: June 2024

Overview

The Farmtrac 450DTC is a utility tractor that is purpose-built to provide a balance of power and functionality for a variety of tasks. Equipped with a 4-wheel drive chassis, it operates with a potent 45 horsepower diesel engine with a liquid-cooling system, ensuring prolonged operating times while minimizing the risk of overheating. The tractor's 4-cylinder engine displaces 141 cubic inches, indicating it provides plenty of torque for heavy-duty use. A hallmark of this model is its transmission system, which features an 8-speed shuttle transmission, offering the operator smooth directional changes with 8 gears both in forward and reverse. The tractor offers different tire options for agricultural, lawn/turf, and industrial applications, suggesting its versatility in various working conditions. The operating weight at 4440 lbs underscores its robustness and capability. The physical footprint of the tractor at 137 inches in length, 62 inches in width, and 93 inches in height allows for its use in a range of environments. With its three-point hitch system categorized under Category II, the Farmtrac 450DTC can handle various attachments and implements, making it a diverse workhorse on the farm or job site.
Show more...

Key Specifications

Category: Utility

Power Output: 45

Transmission: Shuttle

Drive Type: 4WD

Operating Weight: 4440

Fuel Type: Diesel

Farmtrac 450DTC vs. Similar Tractors

Power Output
Average
Greater than 43% of similar tractors.
Operating Weight
Average
Greater than 40% of similar tractors.

Technical Specifications

Engine

Manufacturer
Farmtrac
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
141
Bore (in)
-
Stroke (in)
-
Rated RPM
-
Power Output (hp)
45

Transmission

Type
Shuttle
Forward Gears
8
Reverse Gears
8
Total Gears
16

Dimensions

Length (in)
137
Width (in)
62
Height (in)
93
Operating Weight (lb)
4440

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
Front: 20 (Ag) / 16 (turf) / 18 (industrial)
Front Tire Width (in)
Front: 8.3 (Ag) / 12.5 (turf) / 10.5 (industrial)
Rear Tire Diameter (in)
Rear: 28 (Ag) / 20 (turf) / 24 (industrial)
Rear Tire Width (in)
Rear: 12.4 (Ag) / 44 (turf) / 17.5 (industrial)
Front/Rear Rim Diameter (in)
-
Tire Type
Ag, Lawn/Turf, Industrial
Manufacture - End Year
-
Hitch Type
Category II Three-Point Hitch
Hitch Category
3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric (12 volts)
Brake Type
-
Hydraulic System Type
-
