Farm Pro 7040

Last Updated: June 2024

Overview

The Farm Pro 7040 is a utility tractor designed to handle a variety of tasks on the farm. It's equipped with a robust four-wheel-drive (4WD) chassis and powered by a turbocharged Perkins diesel engine with a displacement of 243.798 cubic inches, delivering 70 horsepower and achieving a rated RPM of 2200. The tractor features an 8-speed manual transmission with 8 forward and 2 reverse gears. The steering system is power-assisted, enhancing maneuverability. It has a Category II hitch type, and while the lift capacity is not specified, its substantial operating weight of 7,507 lbs and rear hitch suggest it's ready for significant workloads. The tractor's durability is highlighted by its engine's large oil and coolant capacities, essential for long working hours in demanding conditions. Dimensions such as the length of 157.9 inches, width of 75.9 inches, and height—most likely at the exhaust—of 101.1 inches, indicate a substantial footprint, which is beneficial for stability during operation.
Show more...

Key Specifications

Category: Utility

Power Output: 70

Transmission: Manual

Drive Type: 4WD

Operating Weight: 7507

Fuel Type: Diesel

Farm Pro 7040 vs. Similar Tractors

Power Output
Average
Greater than 64% of similar tractors.
Operating Weight
Average
Greater than 54% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
243.798
Bore (in)
3.94
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
70

Transmission

Type
Manual
Forward Gears
8
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
157.9
Width (in)
75.9
Height (in)
101.1 (assuming exhaust is the highest point as cab height is less)
Operating Weight (lb)
7507

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
15.84
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Unknown (both cab and exhaust heights are given, but no explicit mention of the operator station type)
Starter Type
-
Brake Type
-
Hydraulic System Type
-
