Farm Pro 2430

Last Updated: June 2024

Overview

The Farm Pro 2430 is a 4WD compact utility tractor manufactured by Jinma for distributor Farm Pro in China from 2002 to 2006. It features a TY395 three-cylinder diesel engine with a liquid-cooling system. This engine boasts a displacement of 136.3 cubic inches and operates at a rated RPM of 2000, delivering 30 horsepower. It is equipped with power steering, disc brakes, a ROPS canopy, and a fuel tank capacity of 7.9 US gallons. Its manual transmission includes 8 forward gears and 2 reverse gears, complemented by a live PTO system with speeds of 540 and 720 rpm. The tractor measures 127.5 inches in length, 56.5 inches in width, and 96 inches in height, with an operating weight of 4380 lbs. It was designed with a Category I hitch, suitable for a range of towing and lifting tasks in the compact utility sector.

Key Specifications

Category: Utility

Power Output: 30

Transmission: Manual

Drive Type: 4WD

Operating Weight: 4380

Fuel Type: Diesel

Image Gallery

Farm Pro 2430 Tractor

Farm Pro 2430 vs. Similar Tractors

Power Output

Below Average

Greater than 25% of similar tractors.

Operating Weight

Average

Greater than 40% of similar tractors.

Technical Specifications

Engine

Manufacturer: Jinma
Model: TY395
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Natural aspirated
Cylinders: 3
Displacement (ci): 136.3
Bore (in): 3.75
Stroke (in): 4.13
Rated RPM: 2000
Power Output (hp): 30

Transmission

Type: Manual
Forward Gears: 8
Reverse Gears: 2
Total Gears: -

Dimensions

Length (in): 127.5
Width (in): 56.5
Height (in): 96
Operating Weight (lb): 4380

Power Take-Off (PTO)

PTO Type: Live (two-stage clutch)
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): 720
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Power
Coolant Capacity (qts): 7.6
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: 2006
Hitch Type: Category I
Hitch Category: Category 3 (Assumed from Hitch Type)
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: ROPS canopy
Starter Type: Electric
Brake Type: Disc
Hydraulic System Type: -
