Eagle Manufacturing E 20-35

Last Updated: June 2024

Overview

The Eagle Manufacturing model E 20-35 is a vintage standard-tread tractor. Its chassis configuration is 4x2 2WD and comes with manual steering. Transmission is gear type with two forward and one reverse gears. Under the hood is a 2-cylinder, liquid-cooled engine that runs on kerosene. The engine has a displacement of 908 ci and is capable of reaching up to 450 RPM. Grinding this tractor to start is a hand-crank type. With rear tire dimensions of 48x14, the tractor has an overall length of 139 inches, width of 73 inches and height of 72 inches. It weighs approximately 7500 lbs when ready for operation.
Show more...

Key Specifications

Category: Utility, Standard Tread

Transmission: Gear

Drive Type: 2WD

Operating Weight: 7500

Fuel Type: Kerosene

Image Gallery

Eagle Manufacturing E 20-35 Tractor Eagle Manufacturing E 20-35 Tractor Eagle Manufacturing E 20-35 Tractor Eagle Manufacturing E 20-35 Tractor Eagle Manufacturing E 20-35 Tractor Eagle Manufacturing E 20-35 Tractor

Eagle Manufacturing E 20-35 vs. Similar Tractors

Operating Weight
Average
Greater than 54% of similar tractors.

Technical Specifications

Engine

Manufacturer
Eagle Manufacturing
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
4 valve (Assumed based on Engine Detail)
Fuel Type
Kerosene
Induction Type
Natural aspiration (Assumed based on no indication of forced induction)
Cylinders
2
Displacement (ci)
908
Bore (in)
8
Stroke (in)
9
Rated RPM
450
Power Output (hp)
-

Transmission

Type
Gear
Forward Gears
2
Reverse Gears
1
Total Gears
-

Dimensions

Length (in)
139
Width (in)
73
Height (in)
72
Operating Weight (lb)
7500

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
48
Rear Tire Width (in)
14
Front/Rear Rim Diameter (in)
-
Tire Type
Steel (Assumed based on "Ag rear: 48x14 (steel)")
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Open (Assumed based on age and tractor type)
Starter Type
Hand-crank
Brake Type
-
Hydraulic System Type
-
