Eagle Manufacturing D 12-22

Last Updated: June 2024

Overview

The Eagle Manufacturing D 12-22 is a standard-tread tractor designed for a variety of agricultural tasks. It features a robust 2-cylinder, 4-valve, kerosene-fueled engine with a displacement of 616 cubic inches, cooled by a liquid-cooled system. The tractor operates on a 2WD drive system with manual steering and a gear-type transmission. The rear tires are sized at 44x12 and are made of steel, which offers impressive durability and traction. The tractor measures 120 inches in length, 70 inches in width, and 60 inches in height, with an operating weight of 5200 lbs. The D 12-22 is started by a hand-crank system, embodying the classic start-up method of old-school tractors.
Show more...

Key Specifications

Category: Utility, Standard Tread

Transmission: Gear

Drive Type: 2WD

Operating Weight: 5200

Fuel Type: Kerosene

Image Gallery

Eagle Manufacturing D 12-22 Tractor Eagle Manufacturing D 12-22 Tractor Eagle Manufacturing D 12-22 Tractor Eagle Manufacturing D 12-22 Tractor Eagle Manufacturing D 12-22 Tractor Eagle Manufacturing D 12-22 Tractor

Eagle Manufacturing D 12-22 vs. Similar Tractors

Operating Weight
Average
Greater than 44% of similar tractors.

Technical Specifications

Engine

Manufacturer
Eagle Manufacturing
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
4-valve
Fuel Type
Kerosene
Induction Type
-
Cylinders
2
Displacement (ci)
616
Bore (in)
7
Stroke (in)
8
Rated RPM
400
Power Output (hp)
-

Transmission

Type
Gear
Forward Gears
-
Reverse Gears
-
Total Gears
-

Dimensions

Length (in)
120
Width (in)
70
Height (in)
60
Operating Weight (lb)
5200

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
32
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
44
Rear Tire Width (in)
12
Front/Rear Rim Diameter (in)
-
Tire Type
Steel (Rear)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Hand-crank
Brake Type
-
Hydraulic System Type
-
