Deutz-Fahr M600

Last Updated: June 2024

Overview

The Deutz-Fahr M600, manufactured between 2007 and 2009, offers a powerful engine output of 121 horsepower. The 6-cylinder engine is turbocharged, intercooled, and dissipates heat through a liquid-cooling system. The tractor employs a partial power shift transmission with a total of 48 gears (24 forward and reverse respectively). Weighing in at 12,040 pounds, the M600 also encompasses a length of 180.7 inches and stands at a height of 115 inches.

Key Specifications

Power Output: 121

Transmission: Partial power shift

Drive Type: 4WD

Operating Weight: 12040

Fuel Type: Diesel

Image Gallery

Deutz-Fahr M600 Tractor

Technical Specifications

Engine

Manufacturer: Deutz
Model: -
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: 12-Valve
Fuel Type: Diesel
Induction Type: Turbocharged and Intercooled
Cylinders: 6
Displacement (ci): 369.6
Bore (in): 3.98
Stroke (in): 4.96
Rated RPM: 2100
Power Output (hp): 121

Transmission

Type: Partial power shift
Forward Gears: 24
Reverse Gears: 24
Total Gears: 48

Dimensions

Length (in): 180.7
Width (in): -
Height (in): 115
Operating Weight (lb): 12040

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: -
Manufacture - End Year: 2009
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric
Brake Type: -
Hydraulic System Type: Open Center
