Deutz-Fahr Agrotron 110

Last Updated: June 2024

Overview

The Deutz-Fahr Agrotron 110 is a row-crop tractor that utilizes a liquid-cooled turbocharged diesel engine. With 6 cylinders, this tractor boasts a power output of 105 horsepower and can reach a rated RPM of 2300. The Agrotron 110 runs on a 4x4 (MFWD 4WD) drive system and utilizes a four-speed power shift transmission, offering a total of 24 gears for both forward and reverse operations. The tractor is built sturdy on a wheelbase length of 104.3 inches, and has a considerable operating weight of 11047 pounds which translates into notable towing capacity. With the cab's height reaching 113 inches, it provides comfortable operation for tasks that demand longer operating hours.
Show more...

Key Specifications

Category: Row Crop

Power Output: 105

Transmission: Four-speed power shift

Drive Type: 4WD

Operating Weight: 11047

Fuel Type: Diesel (turbocharged)

Image Gallery

Deutz-Fahr Agrotron 110 Tractor Deutz-Fahr Agrotron 110 Tractor Deutz-Fahr Agrotron 110 Tractor Deutz-Fahr Agrotron 110 Tractor Deutz-Fahr Agrotron 110 Tractor Deutz-Fahr Agrotron 110 Tractor Deutz-Fahr Agrotron 110 Tractor Deutz-Fahr Agrotron 110 Tractor

Deutz-Fahr Agrotron 110 vs. Similar Tractors

Power Output
Below Average
Greater than 25% of similar tractors.
Operating Weight
Average
Greater than 40% of similar tractors.

Technical Specifications

Engine

Manufacturer
Deutz
Model
BF6L1012E
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel (turbocharged)
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
292.16
Bore (in)
3.7
Stroke (in)
4.52
Rated RPM
2300
Power Output (hp)
105

Transmission

Type
Four-speed power shift
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
178
Width (in)
-
Height (in)
113 (cab height)
Operating Weight (lb)
11047

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 (MFWD 4WD)
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
16.9
Rear Tire Diameter (in)
-
Rear Tire Width (in)
18.4
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category III/II
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
