Deutz-Fahr Agrotron 106

Last Updated: June 2024

Overview

The Deutz-Fahr Agrotron 106 is a robust Row-Crop tractor ideal for various farming tasks. Equipped with a powerful and reliable Deutz BF6L1012E engine, it delivers 100 horsepower. This turbocharged diesel engine comprises 6 cylinders, providing efficient fuel consumption and potent performance under heavy workloads. The Agrotron 106 sports a 24-speed four-speed power shift transmission, ensuring smooth and efficient gear shifting. The chassis incorporates a 4x4 MFWD 4WD setup, offering excellent stability and traction on varied terrains. The tractor measures 178 inches in length and 113 inches in height, with a generous ground clearance of 20.5 inches. The total operating weight for this model is approximately 11047 lbs.
Show more...

Key Specifications

Category: Row Crop

Power Output: 100 hp

Transmission: Four-speed power shift

Drive Type: 4WD

Operating Weight: 11047 lbs

Fuel Type: Diesel

Image Gallery

Deutz-Fahr Agrotron 106 Tractor Deutz-Fahr Agrotron 106 Tractor Deutz-Fahr Agrotron 106 Tractor Deutz-Fahr Agrotron 106 Tractor Deutz-Fahr Agrotron 106 Tractor Deutz-Fahr Agrotron 106 Tractor Deutz-Fahr Agrotron 106 Tractor Deutz-Fahr Agrotron 106 Tractor

Deutz-Fahr Agrotron 106 vs. Similar Tractors

Power Output
Below Average
Greater than 22% of similar tractors.
Operating Weight
Average
Greater than 40% of similar tractors.

Technical Specifications

Engine

Manufacturer
Deutz
Model
BF6L1012E
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
Turbocharged
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
292.16
Bore (in)
3.70 inches
Stroke (in)
4.52 inches
Rated RPM
2300 RPM
Power Output (hp)
100 hp

Transmission

Type
Four-speed power shift
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
178
Width (in)
-
Height (in)
113 inches
Operating Weight (lb)
11047 lbs

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
16.9
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
III/II
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
-
Brake Type
-
Hydraulic System Type
-
