Deutz-Fahr 6180 TTV

Last Updated: June 2024

Overview

The Deutz-Fahr 6180 TTV is a Row-Crop tractor designed with durability and versatility in mind. It is characterized by a powerful Deutz TCD 6.1 L06 4V, turbocharged, intercooled, liquid-cooled diesel engine with six cylinders, capable of delivering a power output of 165 horsepower. The 6180 TTV features a 4x4 MFWD 4WD chassis and is equipped with power steering for easy handling. The tractor is sizeable, with a length of 187.3 inches, a width of 100.4 inches, and an operating weight of 23149 lbs. Further details regarding specific specifications like transmission type, starter type, PTO type, and brake type remain unknown.
Show more...

Key Specifications

Category: Row Crop

Power Output: 165

Transmission: Load sensing

Drive Type: 4WD

Operating Weight: 23149

Fuel Type: Diesel

Image Gallery

Deutz-Fahr 6180 TTV Tractor Deutz-Fahr 6180 TTV Tractor Deutz-Fahr 6180 TTV Tractor Deutz-Fahr 6180 TTV Tractor Deutz-Fahr 6180 TTV Tractor Deutz-Fahr 6180 TTV Tractor Deutz-Fahr 6180 TTV Tractor Deutz-Fahr 6180 TTV Tractor Deutz-Fahr 6180 TTV Tractor Deutz-Fahr 6180 TTV Tractor Deutz-Fahr 6180 TTV Tractor Deutz-Fahr 6180 TTV Tractor

Deutz-Fahr 6180 TTV vs. Similar Tractors

Power Output
Average
Greater than 61% of similar tractors.
Operating Weight
Above Average
Greater than 77% of similar tractors.

Technical Specifications

Engine

Manufacturer
Deutz-Fahr
Model
TCD 6.1 L06 4V
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged intercooled
Cylinders
6
Displacement (ci)
369.6
Bore (in)
3.98
Stroke (in)
4.96
Rated RPM
2100
Power Output (hp)
165

Transmission

Type
Load sensing
Forward Gears
-
Reverse Gears
-
Total Gears
-

Dimensions

Length (in)
187.3
Width (in)
100.4
Height (in)
118.5
Operating Weight (lb)
23149

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
