Deutz-Fahr 4060E Keyline

Last Updated: June 2024

Overview

The Deutz-Fahr 4060E Keyline is a utility tractor suitable for various agricultural tasks. Its chassis is a 4x2 2WD, providing reasonable maneuverability and stability, and it uses a powerful 59.1 hp SDF 1000.3 engine, which features a turbocharged intercooled diesel system. This 3-cylinder engine has a displacement of 183.1 ci and is cooled through a liquid system. The tractor offers several different transmission types, including Gear, Creeper, and partially synchronized options, providing versatile controlling system for different tasks. Its operational weight ranges from 4630 to 5512 pounds, and dimensions are 139.8 inches in length and 70.9 inches in width, with a height to the steering wheel of 64.3 inches.
Show more...

Key Specifications

Category: Utility

Power Output: 59.1

Transmission: Gear, Creeper, Partially synchronized

Drive Type: 2WD

Operating Weight: 4630 - 5512

Fuel Type: Diesel

Image Gallery

Deutz-Fahr 4060E Keyline Tractor Deutz-Fahr 4060E Keyline Tractor Deutz-Fahr 4060E Keyline Tractor Deutz-Fahr 4060E Keyline Tractor Deutz-Fahr 4060E Keyline Tractor Deutz-Fahr 4060E Keyline Tractor

Deutz-Fahr 4060E Keyline vs. Similar Tractors

Power Output
Average
Greater than 56% of similar tractors.
Operating Weight
Above Average
Greater than 87% of similar tractors.

Technical Specifications

Engine

Manufacturer
SDF
Model
1000.3
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged, intercooled
Cylinders
3
Displacement (ci)
183.1
Bore (in)
4.13
Stroke (in)
4.56
Rated RPM
2200
Power Output (hp)
59.1

Transmission

Type
Gear, Creeper, Partially synchronized
Forward Gears
8 (Gear), 12 (Creeper)
Reverse Gears
2 (Gear), 3 (Creeper)
Total Gears
-

Dimensions

Length (in)
139.8
Width (in)
70.9
Height (in)
64.3
Operating Weight (lb)
4630 - 5512

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
II (Rear Type)
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
