Daedong LK4504

Last Updated: June 2024

Key Specifications

Power Output: 46

Transmission: Constant

Drive Type: 4WD

Operating Weight: 3594

Fuel Type: Diesel

Lift Capacity: 2519 lbs

Image Gallery

Daedong LK4504 Tractor Daedong LK4504 Tractor Daedong LK4504 Tractor Daedong LK4504 Tractor Daedong LK4504 Tractor Daedong LK4504 Tractor Daedong LK4504 Tractor Daedong LK4504 Tractor Daedong LK4504 Tractor Daedong LK4504 Tractor

Technical Specifications

Engine

Manufacturer
Daedong
Model
4A220A
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
134.1
Bore (in)
3.425
Stroke (in)
3.638
Rated RPM
2800
Power Output (hp)
46

Transmission

Type
Constant
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
130.3
Width (in)
58.3
Height (in)
88.98
Operating Weight (lb)
3594

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
9.5
Rear Tire Diameter (in)
-
Rear Tire Width (in)
13.6
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
3-Point Hitch
Hitch Category
Category I
Hitch Position
-
Hitch Capacity (lb)
2519 lbs
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
