Daedong DK35

Last Updated: June 2024

Overview

The Daedong DK35 is a sturdy and efficient tractor that comes with a liquid-cooled, 3-cylinder diesel engine, boasting 35 horsepower and a rated RPM of 2700. The engine's displacement is 100.5 ci. The DK35 has an 8-speed transmission system with 8 forward and reverse gears. This model operates on a four-wheel drive with a 4x4 MFWD 4WD chassis. While the specific dimensions vary depending on the type of tire (Ag, Lawn/Turf, or Industrial), the tractor generally measures 126.3 inches in length, 57.1 inches in width, and 92.5 inches in height. It has a weight of 3,475 lbs.
Show more...

Key Specifications

Power Output: 35

Transmission: 8-Speed

Drive Type: 4WD

Operating Weight: 3475

Fuel Type: Diesel

Image Gallery

Daedong DK35 Tractor Daedong DK35 Tractor Daedong DK35 Tractor Daedong DK35 Tractor Daedong DK35 Tractor Daedong DK35 Tractor Daedong DK35 Tractor Daedong DK35 Tractor Daedong DK35 Tractor Daedong DK35 Tractor

Technical Specifications

Engine

Manufacturer
Daedong
Model
3A165D
Cooling Type
Liquid-Cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
100.5
Bore (in)
-
Stroke (in)
-
Rated RPM
2700
Power Output (hp)
35

Transmission

Type
8-Speed
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
126.3
Width (in)
57.1
Height (in)
92.5
Operating Weight (lb)
3475

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag, Lawn/Turf, Industrial
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category I
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
