Daedong CK20

Last Updated: September 2024

Overview

The Daedong CK20 is a compact 4WD tractor designed for various farming tasks. It features a 4x4 MFWD chassis and hydrostatic power steering, making it easy to maneuver in tight spaces. The tractor offers both manual and hydrostatic transmission options, with 6 forward gears and 2 reverse gears, giving operators flexibility in different working conditions.

Under the hood, the CK20 is powered by a Daedong 3C093 engine. This diesel engine is liquid-cooled and has 3 cylinders, with a displacement of 56.6 cubic inches. It delivers 21 horsepower at 2800 RPM, providing enough power for small to medium-sized farm jobs. The tractor's compact size, measuring 105.7 inches long, 44.1 inches wide, and 77.5 inches tall, allows it to work well in orchards, vineyards, and other confined areas.

The CK20 has an operating weight of 1962 pounds, making it sturdy yet not too heavy for delicate soil conditions. It comes equipped with a Category I three-point hitch that can lift up to 1109 pounds, suitable for attaching various implements. This versatile tractor from Daedong is a good choice for small-scale farmers and hobby farm owners looking for a reliable and efficient machine for their daily tasks.
Show more...

Key Specifications

Power Output: 21 hp (15.7 kW)

Transmission: Manual and Hydrostatic

Drive Type: 4WD

Operating Weight: 1962 lb (890 kg)

Fuel Type: Diesel

Daedong CK20 vs. Similar Tractors

Power Output

The Power Output for the Daedong CK20 is Below Average. It is greater than 11% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 6.6K+ tractors in our database)

Operating Weight

The Operating Weight for the Daedong CK20 is Below Average. It is greater than 12% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 6.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Daedong CK20 is Poor. It is greater than 7% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Daedong CK20 is Excellent. It is greater than 93% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Daedong
Model
3C093
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Cylinders
3
Displacement
57 ci (0.9 L)
Bore
2.95 in (74.9 mm)
Stroke
2.76 in (70.1 mm)
Rated RPM
2800
Power Output
21 hp (15.7 kW)

Transmission

Type
Manual and Hydrostatic
Forward Gears
6
Reverse Gears
2

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic Power
