Daedong 4040

Last Updated: June 2024

Overview

The Daedong 4040 is a robust utility tractor, which, based on its specifications, is suitable for a range of agricultural tasks. The 4040 model's engine, an SL3105BT, is a three-cylinder unit with a displacement of 174.4 cubic inches, generating a gross power of 44 horsepower at 2400 RPM. The power take-off (PTO) power is rated at 36 horsepower. While the engine's cooling system capacity is indicated, the specific type of cooling is not provided, although it can be inferred to be liquid-cooled given the fluid capacity.

Physically, the tractor's overall length is approximately 139.2 inches, with a width of 84 inches and a height at the top of the cab at 69.6 inches. The tractor's weight is substantial at 4166.8 pounds, indicative of its sturdy construction. The front tires measure 8.3 inches wide with a diameter of 20 inches, and the rear tires are 12.4 inches wide with a 28-inch diameter, which suggests a stable and balanced ride for various terrains.

In terms of operational characteristics, the Daedong 4040 offers a three-point hitch with a lift capacity of over 5700 pounds, which is compatible with a wide range of implements. The tractor's gear-driven transmission boasts 8 forward gears and 4 reverse, allowing for flexibility in speed and task management. The tractor is likely to have a manual steering system, although this is not explicitly stated in the data provided.

Concluding, the Daedong 4040 tractor is designed for reliability and utility in various agricultural applications. With its considerable power, versatile hitch options, and robust build, it stands as a solid choice for farmers seeking a practical workhorse.
Show more...

Key Specifications

Power Output: 44.0

Transmission: Gear

Operating Weight: 4,167

Lift Capacity: 5732

Technical Specifications

Engine

Manufacturer
Daedong
Model
SL3105BT
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
-
Cylinders
3
Displacement (ci)
174.4
Bore (in)
-
Stroke (in)
-
Rated RPM
2400
Power Output (hp)
44.0

Transmission

Type
Gear
Forward Gears
8
Reverse Gears
4
Total Gears
12

Dimensions

Length (in)
139.2
Width (in)
84.0
Height (in)
69.6
Operating Weight (lb)
4,167

Power Take-Off (PTO)

PTO Type
Rear PTO
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
9.6
Front Tire Diameter (in)
20.0
Front Tire Width (in)
8.3
Rear Tire Diameter (in)
28
Rear Tire Width (in)
12.4
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Three-Point Hitch
Hitch Category
Category 2
Hitch Position
Rear
Hitch Capacity (lb)
5732
Operator Station Type
Cab
Starter Type
-
Brake Type
-
Hydraulic System Type
-
