Cub Cadet 5264

Last Updated: September 2024

Overview

The Cub Cadet 5264 is a small but mighty utility tractor. It's perfect for small farms and big yards. This tractor has a 4-wheel drive system and hydrostatic power steering, making it easy to control. The engine is made by Daihatsu and runs on diesel fuel. It has 3 cylinders and can produce 26 horsepower, which is average for its size. The tractor uses a hydrostatic transmission, giving it smooth speed changes in both forward and reverse.

This compact tractor is 85 inches long, 45 inches wide, and 51 inches tall. It weighs 1,350 pounds, which is lighter than many other tractors. The Cub Cadet 5264 has a liquid-cooled engine that helps it run smoothly in different weather. It also has an electric starter, so you can get to work quickly. The hydraulic system is an open center type, which is good for using attachments. Overall, the Cub Cadet 5264 is a handy tractor for small jobs and everyday use on farms or large properties.
Show more...

Key Specifications

Category: Utility

Power Output: 26 hp (19.4 kW)

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 1350 lb (612 kg)

Fuel Type: Diesel

Cub Cadet 5264 vs. Similar Tractors

Power Output

The Power Output for the Cub Cadet 5264 is Below Average. It is greater than 20% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.7K+ tractors in our database)

Operating Weight

The Operating Weight for the Cub Cadet 5264 is Poor. It is greater than 4% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 4.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Cub Cadet 5264 is Poor. It is greater than 5% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Cub Cadet 5264 is Excellent. It is greater than 100% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Daihatsu
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Cylinders
3
Displacement
58 ci (1.0 L)
Bore
2.83 in (72.0 mm)
Stroke
3.07 in (78.0 mm)
Rated RPM
3600
Power Output
26 hp (19.4 kW)

Transmission

Type
Hydrostatic
Forward Gears
Infinite
Reverse Gears
Infinite

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
