Cub Cadet 1720

Last Updated: June 2024

Overview

The Cub Cadet 1720 is a 2WD lawn tractor manufactured by Cub Cadet (a part of MTD) from 1988 to 1991. This model is equipped with a 0.7 L (42.2 cu·in) two-cylinder gasoline engine and a hydrostatic transmission with infinite forward and reverse gears. In addition, it has a manual steering and dry disc brakes, an open operator station, and comes with a fuel tank that can hold 11.4 liters (3 US gal.; 2.5 Imp. gal). The Cub Cadet 1720 lawn tractor used the Kohler Magnum MV18 engine, a naturally aspirated gasoline engine.

Key Specifications

Category: Lawn and Garden

Power Output: 17

Transmission: Hydrostatic

Drive Type: 2WD

Operating Weight: 4211

Fuel Type: Gasoline

Image Gallery

Cub Cadet 1720 Tractor

Cub Cadet 1720 vs. Similar Tractors

Power Output

Average

Greater than 45% of similar tractors.

Operating Weight

Excellent

Greater than 95% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kohler
Model: MV18
Cooling Type: Air-Cooled
Cylinder Orientation: V
Valve Configuration: -
Fuel Type: Gasoline
Induction Type: Natural Aspirated
Cylinders: 2
Displacement (ci): 42.2
Bore (in): 3.11
Stroke (in): 2.76
Rated RPM: -
Power Output (hp): 17

Transmission

Type: Hydrostatic
Forward Gears: Infinite
Reverse Gears: Infinite
Total Gears: -

Dimensions

Length (in): 68.1
Width (in): -
Height (in): -
Operating Weight (lb): 4211

Power Take-Off (PTO)

PTO Type: Independent with electric clutch
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD
Steering Type: Manual
Coolant Capacity (qts): -
Front Tire Diameter (in): 15
Front Tire Width (in): 6
Rear Tire Diameter (in): 20
Rear Tire Width (in): 10
Front/Rear Rim Diameter (in): -
Tire Type: Lawn/Turf
Manufacture - End Year: 1991
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: Open operator station
Starter Type: Electric
Brake Type: Dry disc
Hydraulic System Type: -
