Cletrac DD

Last Updated: June 2024

Overview

The DD model tractor from manufacturer Cletrac is equipped with a Hercules DRXB engine. It comes with a 6-cylinder, liquid-cooled vertical I-head diesel engine with a displacement of 474 ci. The bore and stroke are 4.375 and 5.25 inches, respectively, and the engine operates at 1300 RPM. The gear type transmission provides four gears forward and two reverse. The tractor is relatively large, with a length of 128 inches and height of 67 inches. Its operating weight is quite significant at 13300 lbs. The coolant capacity is also fairly high at 41 quarts. The specifics about tire configuration, operating station, PTO type, and braking, among other specs, are unknown.

Key Specifications

Transmission: Gear

Operating Weight: 13300 lbs

Fuel Type: Diesel

Image Gallery

Cletrac DD Tractor

Technical Specifications

Engine

Manufacturer: Hercules
Model: DRXB
Cooling Type: Liquid-cooled
Cylinder Orientation: Vertical
Valve Configuration: I-head
Fuel Type: Diesel
Induction Type: -
Cylinders: 6
Displacement (ci): 474 ci
Bore (in): 4.375 inches
Stroke (in): 5.25 inches
Rated RPM: 1300 RPM
Power Output (hp): -

Transmission

Type: Gear
Forward Gears: 4
Reverse Gears: 2
Total Gears: -

Dimensions

Length (in): 128
Width (in): -
Height (in): 67
Operating Weight (lb): 13300 lbs

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: -
Drive Type: -
Steering Type: -
Coolant Capacity (qts): 41 quarts
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: -
Manufacture - End Year: -
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric. Volts: 24
Brake Type: -
Hydraulic System Type: -
