Claas Xerion 2500

Last Updated: June 2024

Overview

The Claas Xerion 2500 tractor features a dynamic 4x4 wheel drive system, enhanced with a hydrostatic power steering for smooth maneuverability. Powered by a 6-cylinder Perkins engine, either the 1306 or 1306-EDi, this tractor boasts power outputs of 250 hp or 265 hp in different versions. The engine utilizes an intercooled turbo induction system and has a displacement of 530 cubic inches. Remarkably, the tractor operates at a rated RPM of 2100. The tractor's overall weight differs between two versions, one weighing in at 20,948 lbs and the other at 23,153 lbs. The tractor's dimensions seem suitable for various farm tasks, with a length of 248 inches and a height of 137.8 inches. It rides on agricultural tires and has a wheelbase of 114.2 inches.

Key Specifications

Power Output: 250, 265 (Two versions provided)

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 20,948, 23,153 (Two versions provided)

Image Gallery

Claas Xerion 2500 Tractor

Technical Specifications

Engine

Manufacturer: Perkins
Model: 1306, 1306-EDi
Cooling Type: -
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: -
Induction Type: Intercooled Turbo
Cylinders: 6
Displacement (ci): 530
Bore (in): 4.591
Stroke (in): 5.315.9 (Possible error on data source, checking for "stroke" only gives 5.315)
Rated RPM: 2100
Power Output (hp): 250, 265 (Two versions provided)

Transmission

Type: Hydrostatic
Forward Gears: Infinite
Reverse Gears: Infinite
Total Gears: -

Dimensions

Length (in): 248
Width (in): -
Height (in): 137.8
Operating Weight (lb): 20,948, 23,153 (Two versions provided)

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 4WD, 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Hydrostatic Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: -
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: -
Brake Type: -
Hydraulic System Type: -
