Claas Arion 430

Last Updated: June 2024

Overview

The Claas Arion 430 is a functional and efficient row-crop tractor, ideal for all types of field work. It is equipped with a 4x4 MFWD 4WD chassis that performs well under any condition. The tractor has a power steering that ensures smooth and responsive handling. Featuring a 16-speed power shift transmission, the Arion 430 delivers excellent speed and torque for all your farming tasks. Powering the Claas Arion 430 is a liquid-cooled, turbocharged and intercooled diesel engine by John Deere. This 4-cylinder engine has a displacement of 276.4 ci and a rated RPM of 2200. The tractor comes with standard agricultural tires for optimum traction: 14.9R24 at the front and 18.4R34 at the rear. The Arion 430 is notable for its dimensions - it has a length of 174.9 inches, a height of 110.7 inches, and an operating weight of 10800 lbs, making it a sizable and substantial machine for heavy-duty field work.
Show more...

Key Specifications

Category: Row Crop

Power Output: 110

Transmission: Power Shift

Drive Type: 4WD

Operating Weight: 10800

Fuel Type: Diesel

Claas Arion 430 vs. Similar Tractors

Power Output
Below Average
Greater than 29% of similar tractors.
Operating Weight
Average
Greater than 39% of similar tractors.

Technical Specifications

Engine

Manufacturer
John Deere
Model
DPS 4045
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged and Intercooled
Cylinders
4
Displacement (ci)
276.4
Bore (in)
4.19
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
110

Transmission

Type
Power Shift
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
174.9
Width (in)
-
Height (in)
110.7
Operating Weight (lb)
10800

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
24
Front Tire Width (in)
14.9
Rear Tire Diameter (in)
34
Rear Tire Width (in)
18.4
Front/Rear Rim Diameter (in)
-
Tire Type
Standard Tires Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
