Chamberlain 60DA

Last Updated: June 2024

Overview

Chamberlain's 60DA is a standard-tread tractor popular among farmers for its resilience and dependability. Featuring a 4x2 chassis and a 2WD drive type, the 60DA relies on the power of a Detroit Diesel 3-71 engine with a displacement of 212.7 ci. The liquid-cooled, 3-cylinder engine is powered by diesel fuel and performs optimally at 1500 RPM. Its sliding gear transmission features 9 forward gears and 3 reverse gears for seamless maneuvering in the fields. The 60DA is built for dimension and stability, with a length of 135 inches, a width of 68 inches, and a height of 90 inches. The operating weight of 9500 lbs ensures this tractor's steadiness during operation. The model has an electric 12-volt starter and features mechanical recirculating ball steering. The tractor’s Ag type tires - with diameters of 18 inches in the front and 30 inches in the rear - further confirm its agricultural inclination. Tractor specifications like these, establish the Chamberlain 60DA as a solid choice for agricultural needs.
Show more...

Key Specifications

Category: Utility, Standard Tread

Transmission: Sliding gear

Drive Type: 2WD

Operating Weight: 9500

Fuel Type: Diesel

Chamberlain 60DA vs. Similar Tractors

Operating Weight
Average
Greater than 62% of similar tractors.

Technical Specifications

Engine

Manufacturer
Detroit Diesel
Model
Mar-71
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
212.7
Bore (in)
4.25
Stroke (in)
5
Rated RPM
1500
Power Output (hp)
-

Transmission

Type
Sliding gear
Forward Gears
9
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
135
Width (in)
68
Height (in)
90
Operating Weight (lb)
9500

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2
Drive Type
2WD
Steering Type
Mechanical - Recirculating ball
Coolant Capacity (qts)
-
Front Tire Diameter (in)
18
Front Tire Width (in)
7.5
Rear Tire Diameter (in)
30
Rear Tire Width (in)
15
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric - 12 volts
Brake Type
-
Hydraulic System Type
-
