Challenger MT335B

Last Updated: June 2024

Key Specifications

Category: Utility

Power Output: 78

Transmission: 12-speed Synchronized Shuttle

Drive Type: 2WD

Operating Weight: 6614

Fuel Type: Diesel

Image Gallery

Challenger MT335B Tractor Challenger MT335B Tractor Challenger MT335B Tractor Challenger MT335B Tractor Challenger MT335B Tractor Challenger MT335B Tractor Challenger MT335B Tractor Challenger MT335B Tractor Challenger MT335B Tractor Challenger MT335B Tractor

Challenger MT335B vs. Similar Tractors

Power Output
Average
Greater than 69% of similar tractors.
Operating Weight
Average
Greater than 50% of similar tractors.

Technical Specifications

Engine

Manufacturer
Challenger
Model
-
Cooling Type
Liquid-Cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
201.4
Bore (in)
4.13
Stroke (in)
5
Rated RPM
2150
Power Output (hp)
78

Transmission

Type
12-speed Synchronized Shuttle
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
148
Width (in)
76
Height (in)
105 (ROPS), 102.5 (Cab)
Operating Weight (lb)
6614

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
3 Point Hitch
Hitch Category
Cat. I/II
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Either Cab or Open (ROPS)
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
Open Center
