CaseIH STX430

Last Updated: June 2024

Overview

The CaseIH STX430 is a four-wheel drive (4WD) tractor, characterized by its 4x4 articulated drive mode and hydrostatic power steering. It houses a 430 horsepower engine manufactured by Iveco. This engine is a 6-cylinder 24-valve, turbocharged, liquid-cooled diesel engine and is notable for its high power output. The STX430 sports a 16-speed full power shift transmission, supporting 16 forward and 2 reverse gears. The tractor weighs about 41,605 lbs when operational. Additional defining features of the STX430 include a rear IVN hitch type and a pressure flow compensated hydraulic system.

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 430

Transmission: Full power shift

Drive Type: Articulated 4WD

Operating Weight: 41605

Fuel Type: Diesel

Image Gallery

CaseIH STX430 Tractor

CaseIH STX430 vs. Similar Tractors

Power Output

Excellent

Greater than 97% of similar tractors.

Operating Weight

Above Average

Greater than 75% of similar tractors.

Technical Specifications

Engine

Manufacturer: Iveco
Model: -
Cooling Type: Liquid
Cylinder Orientation: -
Valve Configuration: 24-valve
Fuel Type: Diesel
Induction Type: Turbocharged
Cylinders: 6
Displacement (ci): 786
Bore (in): 5.314
Stroke (in): 5.906
Rated RPM: 2000
Power Output (hp): 430

Transmission

Type: Full power shift
Forward Gears: 16
Reverse Gears: 2
Total Gears: -

Dimensions

Length (in): -
Width (in): -
Height (in): -
Operating Weight (lb): 41605

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 articulated 4WD
Drive Type: Articulated 4WD
Steering Type: Hydrostatic power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: -
Manufacture - End Year: -
Hitch Type: IVN
Hitch Category: -
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric Starter
Brake Type: -
Hydraulic System Type: Pressure flow compensated
