CaseIH Steiger 470 Quadtrac

Last Updated: September 2024

Overview

The CaseIH Steiger 470 Quadtrac is a powerful 4WD tractor built for heavy-duty farming tasks. It has a strong engine made by FPT that runs on diesel fuel. This engine has 6 cylinders and can produce up to 470 horsepower, making it great for tough jobs. The tractor uses a special system called selective catalytic reduction (SCR) to control emissions and be more eco-friendly.

This tractor is big and heavy, weighing 46,500 pounds. It has a unique design with four tracks instead of wheels, which helps it move well in different types of soil. The Steiger 470 Quadtrac has a full power shift transmission with 16 forward gears and 2 reverse gears, giving the driver lots of control. It also has a good hydraulic system and a strong hitch at the back for attaching equipment. With its size and power, this tractor is perfect for large farms that need to handle big jobs.
Show more...

Key Specifications

Power Output: 470 hp (350.5 kW)

Transmission: Full power shift

Drive Type: 4WD

Operating Weight: 46500 lb (21092 kg)

Fuel Type: Diesel

CaseIH Steiger 470 Quadtrac vs. Similar Tractors

Power Output

The Power Output for the CaseIH Steiger 470 Quadtrac is Excellent. It is greater than 99% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 6.6K+ tractors in our database)

Operating Weight

The Operating Weight for the CaseIH Steiger 470 Quadtrac is Excellent. It is greater than 99% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 6.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the CaseIH Steiger 470 Quadtrac is Excellent. It is greater than 97% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the CaseIH Steiger 470 Quadtrac is Below Average. It is greater than 18% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
FPT
Cooling Type
Liquid-cooled with viscous fan drive
Fuel Type
Diesel
Induction Type
wastegate turbocharged air-to-air aftercooled
Cylinders
6
Displacement
787 ci (12.9 L)
Bore
5.31 in (134.9 mm)
Stroke
5.91 in (150.1 mm)
Rated RPM
2100
Power Output
470 hp (350.5 kW)

Transmission

Type
Full power shift
Forward Gears
16
Reverse Gears
2

Drivetrain

Chassis
4WD articulated chassis
Drive Type
4WD
Steering Type
Hydraulic articulated
