CaseIH MXU100

Last Updated: June 2024

Overview

The CaseIH MXU100 is a versatile utility tractor capable of fulfilling various agricultural and transportation needs. Equipped with a CNH assorted engine, the MXU100 adopts a diesel-fueled, turbocharged intercooled system, delivering a notable 100 horsepower. Its partial powershift transmission provides an array of gear selections with options of 24, 16, and 12 gears both for forward and reverse directions. The tractor comes in both 2WD and 4WD options, with a wheelbase of 93.3 inches for the 2WD and 94.9 inches for the 4WD variant. The MXU100 is fitted with standard agricultural tires, Front: 7.50x16 for the 2WD and 14.9x24 for the 4WD while the rear tire remains 16.9x38 for both versions. The tractor possesses a height of around 112.4 inches with an operating weight ranging between 9060 pounds (2WD version) to 11200 pounds (4WD version).

Key Specifications

Category: Utility

Power Output: 100

Transmission: Partial Powershift

Drive Type: 2WD / 4WD

Operating Weight: 9060 (2WD) / 11200 (4WD)

Fuel Type: Diesel

Image Gallery

CaseIH MXU100 Tractor

CaseIH MXU100 vs. Similar Tractors

Power Output

Above Average

Greater than 82% of similar tractors.

Operating Weight

Excellent

Greater than 99% of similar tractors.

Technical Specifications

Engine

Manufacturer: CNH
Model: -
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged Intercooled
Cylinders: 4
Displacement (ci): 273.7
Bore (in): 4.094
Stroke (in): 5.196
Rated RPM: 2200
Power Output (hp): 100

Transmission

Type: Partial Powershift
Forward Gears: 24 / 16 / 12 (multiple transmissions available)
Reverse Gears: 24 / 16 / 12 (multiple transmissions available)
Total Gears: -

Dimensions

Length (in): -
Width (in): -
Height (in): 112.4
Operating Weight (lb): 9060 (2WD) / 11200 (4WD)

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 (2WD) / 4x4 (4WD)
Drive Type: 2WD / 4WD
Steering Type: -
Coolant Capacity (qts): -
Front Tire Diameter (in): 16 (2WD), 24 (4WD)
Front Tire Width (in): 7.50 (2WD), 14.9 (4WD)
Rear Tire Diameter (in): 38
Rear Tire Width (in): 16.9
Front/Rear Rim Diameter (in): -
Tire Type: Standard Agricultural
Manufacture - End Year: -
Hitch Type: Type II
Hitch Category: -
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: ROPS / Cab
Starter Type: Electric
Brake Type: -
Hydraulic System Type: Pressure-flow compensated (optional)
