CaseIH MXM130 Maxxum

Last Updated: June 2024

Overview

The CaseIH MXM130 Maxxum is a durable and versatile model equipped with a powerful 129 horsepower engine from CNH. This 4WD tractor features a partial powershift transmission with 18 forward and 6 reverse gears. It houses a liquid-cooled, turbocharged, and intercooled diesel engine equipped with 6 cylinders. With its impressive engine displacement of 456.5 cubic inches, bore and stroke measurements of 4.40 and 5.00 inches respectively, it boasts an operating weight of 11,915 lbs. The design includes a cab for operator comfort and convenience, and a steering flow configuration showcasing the model's closed-center load sensing feature.

Key Specifications

Power Output: 129

Transmission: Partial powershift

Drive Type: 4WD

Operating Weight: 11,915

Fuel Type: Diesel

Image Gallery

CaseIH MXM130 Maxxum Tractor

Technical Specifications

Engine

Manufacturer: CNH
Model: -
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged intercooled
Cylinders: 6
Displacement (ci): 456.5
Bore (in): 4.4
Stroke (in): 5
Rated RPM: 2200
Power Output (hp): 129

Transmission

Type: Partial powershift
Forward Gears: 18
Reverse Gears: 6
Total Gears: -

Dimensions

Length (in): 185.7
Width (in): -
Height (in): 111.4
Operating Weight (lb): 11,915

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: -
Drive Type: 4WD
Steering Type: Closed-center load sensing
Coolant Capacity (qts): 26.8
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: -
Manufacture - End Year: -
Hitch Type: -
Hitch Category: II
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: Cab
Starter Type: Electric Starter (12 Volts)
Brake Type: -
Hydraulic System Type: Closed-center load sensing
