CaseIH JX95 Maxxima

Last Updated: June 2024

Overview

The CaseIH JX95 Maxxima is a 2WD or 4WD utility tractor from the JX series. This tractor was manufactured by Turk Tractor for distributor Case IH in Turkey from 2002 to 2009. The CaseIH JX95 is equipped with a 3.9 L (238.5 cu·in) four-cylinder diesel engine and a mechanical shuttle transmission with 12 forward and 12 reverse gears (20 forward and 12 reverse gears with creeper). The tractor uses the Iveco engine, a four-cylinder turbocharged diesel engine with 104.0 mm (4.09 in) of the cylinder bore and 115.0 mm (4.53 in) of the piston stroke. The compression ratio rating is 18.0:1. This engine produced 93.0 HP at 2,500 rpm of output power. The CaseIH JX95 Maxxima is equipped with hydrostatic power steering, independent wet disc brakes, two-post ROPS or Cab (optional) and a 92.0 liters (24.3 US gal.; 20.2 Imp. gal) fuel tank.
Show more...

Key Specifications

Category: Utility

Power Output: 93

Transmission: Mechanical shuttle

Drive Type: 2WD or 4WD

Operating Weight: 2WD: 6788; 4WD: 7615

Fuel Type: Diesel

Image Gallery

CaseIH JX95 Maxxima Tractor CaseIH JX95 Maxxima Tractor CaseIH JX95 Maxxima Tractor CaseIH JX95 Maxxima Tractor CaseIH JX95 Maxxima Tractor CaseIH JX95 Maxxima Tractor

CaseIH JX95 Maxxima vs. Similar Tractors

Power Output
Above Average
Greater than 78% of similar tractors.
Hitch Capacity
Above Average
Greater than 76% of similar tractors.
Operating Weight
Excellent
Greater than 95% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iveco
Model
-
Cooling Type
Liquid
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
238.5
Bore (in)
4.09
Stroke (in)
4.53
Rated RPM
2500
Power Output (hp)
93

Transmission

Type
Mechanical shuttle
Forward Gears
12 or 20 (with creeper)
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
2WD: 161.8; 4WD: 159.4
Width (in)
71.2
Height (in)
-
Operating Weight (lb)
2WD: 6788; 4WD: 7615

Power Take-Off (PTO)

PTO Type
Independent
PTO Speed 1 (rpm)
540 or 540E (optional)
PTO Speed 2 (rpm)
540 or 1000 (optional)
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD or 4x4 MFWD 4WD (optional)
Drive Type
2WD or 4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
2009
Hitch Type
-
Hitch Category
II
Hitch Position
Rear
Hitch Capacity (lb)
5027 lbs
Operator Station Type
Two-post ROPS or Cab (optional)
Starter Type
Electric
Brake Type
Independent wet disc
Hydraulic System Type
Open center
