CaseIH JX1085C

Last Updated: June 2024

Overview

The CaseIH JX1085C is a diverse and dependable utility tractor designed for a variety of tasks. At its core is a 4-cylinder, liquid-cooled diesel engine developed by CNH, delivering a solid 80 horsepower. The power is managed by a mechanical shuttle transmission system capable of delivering 16 forward and reverse gears. With direct injection fuel system built into the engine, it ensures optimal performance and efficiency. The chassis supports a Four-Wheel Drive and power steering system, ensuring maneuverable navigation over difficult terrains. Its bulk stands tall atop a wheelbase of 86 inches, and can operate at a weight of 6,910 lbs. Hydraulic system follows the open center design, meaning fluid is constantly flowing which ultimately cools and filters the oil. While the operator station is spacious enough to house a cab, it defaults with open type station equipped with a Roll Over Protection Structure (ROPS) installed.
Show more...

Key Specifications

Category: Utility

Power Output: 80

Transmission: Mechanical shuttle

Drive Type: 4WD

Operating Weight: 6910

Fuel Type: Diesel

CaseIH JX1085C vs. Similar Tractors

Power Output
Above Average
Greater than 71% of similar tractors.
Operating Weight
Average
Greater than 52% of similar tractors.

Technical Specifications

Engine

Manufacturer
CNH
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
4
Displacement (ci)
273.7
Bore (in)
4.094
Stroke (in)
5.197
Rated RPM
2300
Power Output (hp)
80

Transmission

Type
Mechanical shuttle
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
157
Width (in)
69.6
Height (in)
95.6 (ROPS) , 91.5 (Cab)
Operating Weight (lb)
6910

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
II
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Open/Cab
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
Open center
