CaseIH Farmall DX48

Last Updated: June 2024

Overview

The CaseIH Farmall DX48 is a compact utility tractor that boasts a potent 48 horsepower engine. It features a diesel, liquid-cooled, 4-cylinder engine that was provided by Shibaura. The engine displacement is 135.2 cubic inches, and it has a bore/stroke of 3.307/3.937 inches. Operating at a rated RPM of 2800, the engine is started using a 12 volts electric starter. With its 4x2 2WD chassis and hydrostatic power steering, maneuverability is a breeze. The tractor is equipped with a 12-speed synchronized shuttle transmission system, providing 12 forward and reverse gears. It has a rear hitch of category I/II. Its operating weight stands at 4,315 lbs. The wheelbase spans 74.8 inches, providing a stable base for varied operations.
Show more...

Key Specifications

Category: Utility

Power Output: 48

Transmission: Synchronized Shuttle

Drive Type: 2WD

Operating Weight: 4,315

Fuel Type: Diesel

Image Gallery

CaseIH Farmall DX48 Tractor CaseIH Farmall DX48 Tractor CaseIH Farmall DX48 Tractor CaseIH Farmall DX48 Tractor CaseIH Farmall DX48 Tractor CaseIH Farmall DX48 Tractor

CaseIH Farmall DX48 vs. Similar Tractors

Power Output
Average
Greater than 46% of similar tractors.
Operating Weight
Poor
Greater than 2% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
135.2
Bore (in)
3.307
Stroke (in)
3.937
Rated RPM
2800
Power Output (hp)
48

Transmission

Type
Synchronized Shuttle
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
4,315

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
I/II
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
