CaseIH Farmall 55

Last Updated: June 2024

Overview

The CaseIH Farmall 55 is a robust and reliable farm/agricultural tractor. The 4x4 MFWD 4WD chassis provides dependable traction while the hydrostatic power steering ensures responsive handling. At the heart of the tractor is a turbocharged diesel engine by Shibaura, sporting 4 cylinders and a displacement of 135.2 cubic inches. This allows the engine to deliver 55 horsepower at a rated RPM of 2700. The transmission system comes in a 12 forward and reverse Synchro Shuttle/Power Shuttle setup, facilitating smooth and efficient movement. With a length of 137.3 inches, a width of 64.4 inches, a height of 95 inches, and a weight of 4209 pounds, this tractor offering from CaseIH balances power with a compact form factor.
Show more...

Key Specifications

Category: Agricultural

Power Output: 55

Transmission: Synchro Shuttle/Power Shuttle

Drive Type: 4WD

Operating Weight: 4209

Fuel Type: Diesel

Image Gallery

CaseIH Farmall 55 Tractor CaseIH Farmall 55 Tractor CaseIH Farmall 55 Tractor CaseIH Farmall 55 Tractor CaseIH Farmall 55 Tractor CaseIH Farmall 55 Tractor CaseIH Farmall 55 Tractor CaseIH Farmall 55 Tractor CaseIH Farmall 55 Tractor CaseIH Farmall 55 Tractor

CaseIH Farmall 55 vs. Similar Tractors

Power Output
Below Average
Greater than 28% of similar tractors.
Operating Weight
Below Average
Greater than 21% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
ISM-N844L-T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
135.2
Bore (in)
3.31
Stroke (in)
3.94
Rated RPM
2700
Power Output (hp)
55

Transmission

Type
Synchro Shuttle/Power Shuttle
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
137.3
Width (in)
-
Height (in)
-
Operating Weight (lb)
4209

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
14.9
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
Open center
