CaseIH Farmall 30B

Last Updated: June 2024

Overview

The CaseIH Farmall 30B is a compact utility tractor powered by a four-cylinder Mitsubishi S4L diesel engine. This engine delivers a gross power output of 28 hp and is cooled by a liquid cooling system. The tractor operates on a 4x4 MFWD 4WD chassis and uses a hydrostatic power steering system. The transmission is either a 12-speed partially synchronized system or a hydrostatic system offering infinite gears in 3 ranges. The tractor has a reported weight of 3,121 lbs and dimensions of 119 inches long and 91 inches high (with a ROPS). The hydraulic system is an open center type.
Show more...

Key Specifications

Category: Utility

Power Output: 28

Transmission: 12-speed partially synchronized / Hydrostatic

Drive Type: 4WD

Operating Weight: 3,121

Fuel Type: Diesel

Image Gallery

CaseIH Farmall 30B Tractor CaseIH Farmall 30B Tractor CaseIH Farmall 30B Tractor CaseIH Farmall 30B Tractor CaseIH Farmall 30B Tractor CaseIH Farmall 30B Tractor CaseIH Farmall 30B Tractor CaseIH Farmall 30B Tractor

CaseIH Farmall 30B vs. Similar Tractors

Power Output
Below Average
Greater than 23% of similar tractors.
Operating Weight
Poor
Greater than 1% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S4L
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
92
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
28

Transmission

Type
12-speed partially synchronized / Hydrostatic
Forward Gears
-
Reverse Gears
-
Total Gears
-

Dimensions

Length (in)
119
Width (in)
-
Height (in)
91 (with ROPS)
Operating Weight (lb)
3,121

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
Open Center
