CaseIH DX29

Last Updated: September 2024

Overview

The CaseIH DX29 is a utility tractor built for versatile farm work. It has a 4-wheel drive system, which helps it move well in tough conditions. The tractor uses a hydrostatic transmission, letting the driver change speeds smoothly without shifting gears.

Under the hood, the DX29 has a Shibaura diesel engine with 3 cylinders. The engine is liquid-cooled and naturally aspirated, producing 29 horsepower at 2800 rpm. While its engine size is below average, it runs at a very high speed compared to other tractors. The DX29 has a Category I rear hitch for attaching various tools. It also comes with helpful features like glow plugs for easy starting in cold weather and a dual-element air cleaner to keep the engine running clean.

Key Specifications

Category: Utility

Power Output: 29 hp (21.6 kW)

Transmission: Hydrostatic

Drive Type: 4WD

Fuel Type: Diesel

Image Gallery

CaseIH DX29 Tractor

CaseIH DX29 vs. Similar Tractors

Power Output

The Power Output for the CaseIH DX29 is Below Average. It is greater than 23% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.7K+ tractors in our database)

Engine Displacement

The Engine Displacement for the CaseIH DX29 is Below Average. It is greater than 15% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the CaseIH DX29 is Excellent. It is greater than 95% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors
