CaseIH CVX 150

Last Updated: June 2024

Overview

This CaseIH CVX 150 tractor features a robust 6-cylinder, turbo diesel Sisu 620.83 engine with an impressive power output of 150 hp. The engine is considerable in size with a displacement of 402.5 ci and a rated RPM of 2300. The tractor has a unique continuously variable transmission, enabling a seamless shifting process, allowing for infinite forward and reverse gears. It boasts a comfortable length of 188.6 inches and an elevated height of 119.7 inches. Operating on a 4x4 MFWD 4WD chassis, it guarantees stability and an impressive weight handling capacity of 14,046 lbs. Despite its robust qualities, specific details of its components such as its cooling type, cylinder orientation, valve configuration, and hitch type remain unknown.
Show more...

Key Specifications

Power Output: 150

Transmission: Continuously Variable

Drive Type: 4WD

Operating Weight: 14046

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Sisu
Model
620.83
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbo
Cylinders
6
Displacement (ci)
402.5
Bore (in)
4.25
Stroke (in)
4.72
Rated RPM
2300
Power Output (hp)
150

Transmission

Type
Continuously Variable
Forward Gears
Infinite
Reverse Gears
Infinite
Total Gears
-

Dimensions

Length (in)
188.6
Width (in)
-
Height (in)
119.7
Operating Weight (lb)
14046

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
