CaseIH CS 68

Last Updated: June 2024

Overview

The CaseIH CS 68 is a reliable utility tractor with either a 4x2 2WD chassis or 4x4 4WD chassis. Equipped with a 68 horsepower, 3 cylinder, naturally aspirated diesel engine from either MWM or Sisu, which provides excellent power and efficiency. The CS 68 offers a power steering system and a 16-speed synchronized transmission for convenient control and maneuverability.

Key Specifications

Category: Utility

Power Output: 68

Transmission: Synchronized

Drive Type: 2WD

Operating Weight: 6217 (2WD) or 6834 (4WD)

Fuel Type: Diesel

Image Gallery

CaseIH CS 68 Tractor

CaseIH CS 68 vs. Similar Tractors

Power Output

Average

Greater than 63% of similar tractors.

Operating Weight

Excellent

Greater than 97% of similar tractors.

Technical Specifications

Engine

Manufacturer: MWM or Sisu
Model: 3.1L 3-cyl diesel or 3.3L 3-cyl diesel
Cooling Type: -
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Natural Aspiration
Cylinders: 3
Displacement (ci): 190.2 or 201.2
Bore (in): 4.13 or 4.25
Stroke (in): 4.72
Rated RPM: 2250 or 2200
Power Output (hp): 68

Transmission

Type: Synchronized
Forward Gears: 16
Reverse Gears: 8
Total Gears: -

Dimensions

Length (in): 145.7 (2WD) or 149.2 (4WD)
Width (in): 74.8
Height (in): 99.2 (with cab)
Operating Weight (lb): 6217 (2WD) or 6834 (4WD)

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: -
Hitch Type: Type II
Hitch Category: -
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: Cab
Starter Type: 12 Volts
Brake Type: -
Hydraulic System Type: -
