CaseIH CS 58

Last Updated: June 2024

Overview

The CaseIH CS 58 is a sturdy and reliable tractor, designed for efficiency and durability. It is powered by a 58 hp Perkins engine, providing robust power for demanding tasks. The CS 58 operates in a 2WD chassis configuration, offering solid traction and maneuverability. Its engine has a healthy displacement of 164.8 ci, with a bore and stroke measurement of 3.74 and 5.00 inches respectively. Equipped with a 16-speed synchro transmission system, the CS 58 ensures smooth and efficient gear shifts. The tractor sits on a sizeable 83.5-inch wheelbase, offering increased stability and support. Despite its solid build, the CS 58 maintains a suitable compact size with a length of 138.6 inches and a height of 93.7 inches. When it comes to weight, the tractor measures at an operating weight of 6,064 lbs.

Key Specifications

Power Output: 58

Transmission: synchro

Drive Type: 2WD

Operating Weight: 6,064

Fuel Type: Diesel

Image Gallery

CaseIH CS 58 Tractor

Technical Specifications

Engine

Manufacturer: Perkins
Model: 903.27T
Cooling Type: -
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged
Cylinders: 3
Displacement (ci): 164.8
Bore (in): 3.74
Stroke (in): 5
Rated RPM: 2250
Power Output (hp): 58

Transmission

Type: synchro
Forward Gears: 16
Reverse Gears: 8
Total Gears: -

Dimensions

Length (in): 138.6
Width (in): -
Height (in): 93.7
Operating Weight (lb): 6,064

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD
Steering Type: power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: -
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: -
Brake Type: -
Hydraulic System Type: -
