CaseIH CS 52

Last Updated: June 2024

Overview

The tractor CS 52 from CaseIH is a versatile utility tractor. Power steering ensures smooth handling while a dry disc clutch and a 16-speed synchronized transmission, provides exceptional control over the tractor's speed and direction. The tractor is powered by a Perkins 903.27T diesel engine with three cylinders providing a power output of 52 horsepower. The tractor's 2WD chassis has an operating weight ranging from 5027 to 5952 pounds. A Type II hitch makes this tractor versatile for different tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 52

Transmission: Synchronized

Drive Type: 2WD

Fuel Type: Diesel

Image Gallery

CaseIH CS 52 Tractor CaseIH CS 52 Tractor CaseIH CS 52 Tractor CaseIH CS 52 Tractor CaseIH CS 52 Tractor CaseIH CS 52 Tractor CaseIH CS 52 Tractor CaseIH CS 52 Tractor CaseIH CS 52 Tractor CaseIH CS 52 Tractor CaseIH CS 52 Tractor CaseIH CS 52 Tractor

CaseIH CS 52 vs. Similar Tractors

Power Output
Average
Greater than 50% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
903.27T
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
164.8
Bore (in)
3.74
Stroke (in)
5
Rated RPM
2250
Power Output (hp)
52

Transmission

Type
Synchronized
Forward Gears
16
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
139 (2WD), 140.6 (4WD)
Width (in)
74.8
Height (in)
-
Operating Weight (lb)
-

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2
Drive Type
2WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
7.5
Rear Tire Diameter (in)
-
Rear Tire Width (in)
14.9
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
II
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
12V Electric Starter
Brake Type
-
Hydraulic System Type
-
