CaseIH CS 130

Last Updated: June 2024

Overview

The CaseIH CS 130 is a robust and powerful row-crop tractor, well-suited for a variety of tasks in the field. It features a 4x4 chassis with an MFWD 4WD drive type for excellent traction and stability. The tractor is outfitted with a power steering system for easy control. The turbocharged Sisu 620.92 engine delivers high power with a rated output of 123.3 hp. The tractor's transmission is a four-speed power shift, with 24 forward and reverse gears. The rear type III hitch allows for convenient connectivity with various farming implements. With a length of 190.2 inches, a width of 96.5 inches, and a weight of 11607 lbs, this tractor promises great performance for all your agricultural needs.

Key Specifications

Category: Row Crop

Power Output: 123.3

Transmission: Four-speed power shift

Drive Type: MFWD 4WD

Operating Weight: 11607

Fuel Type: Diesel

Image Gallery

CaseIH CS 130 Tractor

CaseIH CS 130 vs. Similar Tractors

Power Output

Average

Greater than 37% of similar tractors.

Operating Weight

Average

Greater than 44% of similar tractors.

Technical Specifications

Engine

Manufacturer: Sisu
Model: 620.92
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged
Cylinders: 6
Displacement (ci): 402.8
Bore (in): 4.25
Stroke (in): 4.72
Rated RPM: 2300
Power Output (hp): 123.3

Transmission

Type: Four-speed power shift
Forward Gears: 24 (with creeper: 40)
Reverse Gears: 24 (with creeper: 40)
Total Gears: -

Dimensions

Length (in): -
Width (in): 96.5
Height (in): 115.8
Operating Weight (lb): 11607

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4
Drive Type: MFWD 4WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: -
Manufacture - End Year: -
Hitch Type: Rear Type: III
Hitch Category: -
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: -
Brake Type: -
Hydraulic System Type: -
