CaseIH 9240

Last Updated: June 2024

Key Specifications

Category: Utility, Four-Wheel Drive

Power Output: 235

Transmission: Full power shift

Drive Type: Four-wheel Drive (4WD)

Operating Weight: 28,214

Fuel Type: Diesel

Image Gallery

CaseIH 9240 Tractor CaseIH 9240 Tractor CaseIH 9240 Tractor CaseIH 9240 Tractor CaseIH 9240 Tractor CaseIH 9240 Tractor CaseIH 9240 Tractor CaseIH 9240 Tractor

CaseIH 9240 vs. Similar Tractors

Power Output
Excellent
Greater than 93% of similar tractors.
Operating Weight
Poor
Greater than 6% of similar tractors.

Technical Specifications

Engine

Manufacturer
CaseIH
Model
CDC
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged aftercooled
Cylinders
6
Displacement (ci)
504.5
Bore (in)
4.488
Stroke (in)
5.315
Rated RPM
2200
Power Output (hp)
235

Transmission

Type
Full power shift
Forward Gears
12
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
250.3
Width (in)
93.5 (minimum) / 151.8 (with duals)
Height (in)
143
Operating Weight (lb)
28,214

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 4WD
Drive Type
Four-wheel Drive (4WD)
Steering Type
Four-wheel hydrostatic power
Coolant Capacity (qts)
29.6
Front Tire Diameter (in)
38
Front Tire Width (in)
18.4
Rear Tire Diameter (in)
38
Rear Tire Width (in)
18.4
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
III (Optional Rear Type)
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
Hydraulic wet disc
Hydraulic System Type
Closed center load sensing pressure compensating
