CaseIH 795

Last Updated: June 2024

Overview

The CaseIH 795 is a 77HP utility tractor, well-adapted for several tasks. Featuring a 2WD chassis, 4-cylinder CaseIH D-246 diesel engine with liquid cooling and direct injection, it can deliver robust performance with adequate fuel efficiency. It has a 16 forward and 8 reverse gear transmission that provides a variety of speeds for optimum performance. The hydrostatic power steering aids in smoother and more manageable operation. The tractor has a 2WD wheelbase of 88.2 inches and a weight of around 6376 to 7480 pounds, which provides significant stability during use. With a length of 147.5 inches and cab height of 104.3 inches, it delivers a comfortable operating space. Equipped with standard ag tires, it can perform well in different field conditions.

Key Specifications

Category: Utility

Power Output: 77

Transmission: Manual

Drive Type: 2WD

Operating Weight: 6376 to 7480

Fuel Type: Diesel

Image Gallery

CaseIH 795 Tractor

CaseIH 795 vs. Similar Tractors

Power Output

Average

Greater than 69% of similar tractors.

Operating Weight

Above Average

Greater than 90% of similar tractors.

Technical Specifications

Engine

Manufacturer: CaseIH
Model: D-246
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Direct Injection
Cylinders: 4
Displacement (ci): 246.4
Bore (in): 3.937
Stroke (in): 5.059
Rated RPM: 2300
Power Output (hp): 77

Transmission

Type: Manual
Forward Gears: 16
Reverse Gears: 8
Total Gears: -

Dimensions

Length (in): 147.5
Width (in): -
Height (in): 104.3
Operating Weight (lb): 6376 to 7480

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD
Steering Type: Hydrostatic Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: -
Hitch Type: -
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: Cab
Starter Type: -
Brake Type: -
Hydraulic System Type: -
