Branson 4225H

Last Updated: June 2024

Overview

This Branson 4225H is a compact utility tractor powered by a 4-cylinder, liquid-cooled diesel engine made by Kukje with a displacement of 127.2 cubic inches. It's a 4-wheel drive with a wheelbase of 71.1 inches, and it has a power steering system. The tractor has a hydrostatic transmission, making it efficient and easy to control. It has infinite (3-range) forward and reverse gears, which adds flexibility to its operation. The tractor measures 129 inches in length, 60.2 inches in width, and its height with the Rollover Protection System (ROPS) is 96 inches. It weighs about 4153 lbs. The cooling system capacity is 6.4 quarts and it uses a dual dry element air cleaner.

Key Specifications

Category: Utility

Transmission: Hydrostatic (Infinite forward and reverse gears)

Drive Type: 4WD

Operating Weight: 4153

Fuel Type: Diesel

Image Gallery

Branson 4225H Tractor

Branson 4225H vs. Similar Tractors

Operating Weight

Average

Greater than 38% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kukje
Model: A2000N2-UTR4
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: -
Cylinders: 4
Displacement (ci): 127.2
Bore (in): 3.31
Stroke (in): 3.7
Rated RPM: 2600
Power Output (hp): -

Transmission

Type: Hydrostatic (Infinite forward and reverse gears)
Forward Gears: -
Reverse Gears: -
Total Gears: -

Dimensions

Length (in): 129
Width (in): -
Height (in): -
Operating Weight (lb): 4153

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Power
Coolant Capacity (qts): 6.4
Front Tire Diameter (in): 16
Front Tire Width (in): 9.5
Rear Tire Diameter (in): 28
Rear Tire Width (in): 12.4
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: -
Hitch Type: Rear Type: I
Hitch Category: -
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric
Brake Type: -
Hydraulic System Type: Open Center
