Branson 3515CH

Last Updated: September 2024

Overview

The Branson 3515CH is a compact tractor designed for various farming tasks. It features a 35 hp diesel engine made by Kukje, which is liquid-cooled for better performance. The engine has 4 cylinders and runs at 2600 rpm, providing good power for its size.

This tractor uses a hydrostatic transmission, which means it's easy to operate with smooth speed changes. It has infinite forward and reverse gears in 3 ranges, giving the driver lots of control. The 3515CH comes with a cab for operator comfort and protection from the weather. It has a Type I rear hitch for attaching implements. The tractor is 130 inches long, 55.6 inches wide, and 89.3 inches tall, making it suitable for working in tight spaces. It weighs 3664 pounds, which helps with stability during work. The 3515CH likely has four-wheel drive, which is common for tractors in this class and helps with traction in various conditions.
Show more...

Key Specifications

Power Output: 35 hp (26.1 kW)

Transmission: Hydrostatic

Operating Weight: 3664 lb (1662 kg)

Fuel Type: Diesel

Branson 3515CH vs. Similar Tractors

Power Output

The Power Output for the Branson 3515CH is Below Average. It is greater than 28% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 6.6K+ tractors in our database)

Operating Weight

The Operating Weight for the Branson 3515CH is Below Average. It is greater than 29% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 6.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Branson 3515CH is Average. It is greater than 33% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Branson 3515CH is Above Average. It is greater than 80% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Kukje
Model
A2300NA
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Cylinders
4
Displacement
140 ci (2.3 L)
Bore
3.46 in (87.9 mm)
Stroke
3.70 in (94.0 mm)
Rated RPM
2600
Power Output
35 hp (26.1 kW)

Transmission

Type
Hydrostatic
Forward Gears
Infinite (3-range)
Reverse Gears
Infinite (3-range)
