Bobcat CT1021

Last Updated: June 2024

Overview

The Bobcat CT1021 is a durable sub-compact utility tractor ideal for a variety of tasks. It boasts a powerful 21.1 horsepower Shibaura S733L diesel engine with 3 liquid-cooled cylinders. The tractor features a 4x4 MFWD 4WD chassis and a hydrostatic transmission offering infinite (2-range) forward and reverse gears. Weighing 1488 lbs, this tractor features large tires with a front size of 18x8.5-10 and rear size of 26x12.00-12, providing stability and excellent traction. Tier 4 emissions standards compliance ensures its operation is environmentally friendly. Overall, the Bobcat CT1021 promises high performance and reliability suited for any compact utility tasks.

Key Specifications

Category: Utility, Sub-Compact

Power Output: 21.1

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 1488

Fuel Type: Diesel

Image Gallery

Bobcat CT1021 Tractor

Bobcat CT1021 vs. Similar Tractors

Power Output

Below Average

Greater than 11% of similar tractors.

Operating Weight

Below Average

Greater than 11% of similar tractors.

Technical Specifications

Engine

Manufacturer: Shibaura
Model: S733L
Cooling Type: Liquid cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: -
Cylinders: 3
Displacement (ci): 69.1
Bore (in): 3.03
Stroke (in): 3.19
Rated RPM: 3000
Power Output (hp): 21.1

Transmission

Type: Hydrostatic
Forward Gears: Infinite (2-range)
Reverse Gears: Infinite (2-range)
Total Gears: -

Dimensions

Length (in): 99.3
Width (in): 46
Height (in): 87.6
Operating Weight (lb): 1488

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: -
Coolant Capacity (qts): -
Front Tire Diameter (in): 18
Front Tire Width (in): 8.5
Rear Tire Diameter (in): 26
Rear Tire Width (in): 12
Front/Rear Rim Diameter (in): -
Tire Type: Ag / Industrial
Manufacture - End Year: -
Hitch Type: Rear Type I
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: ROPS
Starter Type: Electric
Brake Type: -
Hydraulic System Type: -
