Belarus MTZ-500

Last Updated: June 2024

Overview

The Belarus MTZ-500 is a tractor designed for general farm use. Powered by a D60, 4-cylinder engine, it outputs a power of 67 horsepower at a rated RPM of 1800. It shows impressive transmission capabilities with 9 forward and 2 reverse gears. The MTZ-500 follows a 4x2 2WD chassis design, indicating it is a two-wheel driven vehicle. With its power-assisted steering, it facilitates easier manoeuvrability during operations. The tractor weighs approximately 6,769 lbs, underlining its stability and sturdiness. It utilizes agricultural tires, with the front tires having a width of 7.00 and rear tires standing at 13.6.
Show more...

Key Specifications

Power Output: 67

Drive Type: 2WD

Operating Weight: 6769

Technical Specifications

Engine

Manufacturer
Belarus
Model
D60
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
-
Cylinders
4
Displacement (ci)
289.8
Bore (in)
4.331
Stroke (in)
4.921
Rated RPM
1800
Power Output (hp)
67

Transmission

Type
-
Forward Gears
9
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
6769

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power assist
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
7
Rear Tire Diameter (in)
-
Rear Tire Width (in)
13.6
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
