Belarus 5290

Last Updated: June 2024

Overview

The Belarus 5290 model features a robust and reliable hydrostatic power steering and a 4x4 MFWD 4WD drive type. It features a partially synchronized transmission with 14 forward and 4 reverse gears. The power in the Belarus 5290 is provided by a 289.9 ci, 4-cylinder, liquid-cooled and turbocharged diesel engine with a rated RPM of 1800. This tractor is designed for optimum performance and it comes with a wheelbase of 96.5 inches, a length of 154.7 inches, and a breadth of 77.6 inches. It stands 66.5 inches high on the hood and 109.6 inches high on the cab. It weighs 8124 lbs, making it sturdy and suitable for heavy-duty work.
Show more...

Key Specifications

Transmission: Partially Synchronized

Drive Type: 4WD

Operating Weight: 8124

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Belarus
Model
D243
Cooling Type
Liquid
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
289.9
Bore (in)
4.33
Stroke (in)
4.92
Rated RPM
1800
Power Output (hp)
-

Transmission

Type
Partially Synchronized
Forward Gears
14
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
154.7
Width (in)
77.6
Height (in)
66.5 (hood), 109.6 (cab)
Operating Weight (lb)
8124

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic Power
Coolant Capacity (qts)
20.1
Front Tire Diameter (in)
-
Front Tire Width (in)
13.6
Rear Tire Diameter (in)
-
Rear Tire Width (in)
18.4
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
II
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
