Belarus 5150

Last Updated: June 2024

Overview

The Belarus Model 5150 is a robust tractor that operates on a 4x4 MFWD 4WD chassis. It features a Belarus-made D244 diesel engine with a displacement of 289.9 ci and four cylinders. The engine is liquid-cooled and has an impressive rated RPM of 1700. The tractor has an 18-gear transmission, and it also uses an Electric starter. The tractor's robust structure and capabilities make it ideal for various heavy-duty applications.

Key Specifications

Transmission: Manual

Drive Type: 4WD

Operating Weight: 7870

Fuel Type: Diesel

Image Gallery

Belarus 5150 Tractor

Technical Specifications

Engine

Manufacturer: Belarus
Model: D244
Cooling Type: Liquid-Cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: -
Cylinders: 4
Displacement (ci): 289.9
Bore (in): 4.33
Stroke (in): 4.92
Rated RPM: 1700
Power Output (hp): -

Transmission

Type: Manual
Forward Gears: 18
Reverse Gears: 4
Total Gears: -

Dimensions

Length (in): 154.7
Width (in): 77.5
Height (in): 64.4 (hood), 108.3 (cab)
Operating Weight (lb): 7870

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Hydrostatic Power
Coolant Capacity (qts): 20.1
Front Tire Diameter (in): -
Front Tire Width (in): 11.2
Rear Tire Diameter (in): -
Rear Tire Width (in): 15.5
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: -
Hitch Type: II
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric
Brake Type: -
Hydraulic System Type: Live Open Center
