AGCO RT180A

Last Updated: July 2024

Overview

The AGCO RT180A is a robust row-crop tractor designed for demanding farming tasks. It comes equipped with a 215 hp SisuDiesel 74CTA six-cylinder turbocharged intercooled engine, capable of reaching up to 245 hp at peak power. The engine displacement is notable at 449.4 cubic inches, with a 4.252-inch bore and 5.276-inch stroke, operating efficiently at a rated RPM of 2200. When it comes to transmission, users have the option of two types: a 24-speed partial power shift or an infinite-gear Powermaxx CVT, suitable for versatile agricultural operations. Its dry cartridge air cleaner, an electronic common rail fuel system coupled with an air-intake grid heater, ensures reliable starts and optimal engine performance. The tractor's thoughtful design extends to a weighting system that supports both operation at 17,460 lbs and a ballasted maximum of 23,920 lbs for improved traction. Given its dimensions, extending up to 210 inches in length and having a minimum width of 79.1 inches, it caters well to row-crop work. Steering is eased via a power steering system, and its 4x2 2WD chassis is designed to maneuver through fields with ease while the cab height reaches 122 inches, providing ample visibility for the operator. While operational specifics like PTO speeds, hitch lift capacity, and manufacture years are unavailable, the AGCO RT180A's specifications speak to its capability in the field.
Show more...

Key Specifications

Category: Row Crop

Power Output: 216.2 hp (161.2 kW) at 2000 rpm

Transmission: Selective gear fixed ratio with partial (6) range operator controlled power shift

Operating Weight: 17460

Fuel Type: Diesel

AGCO RT180A vs. Similar Tractors

Power Output
Excellent
Greater than 96% of similar tractors.
Operating Weight
Average
Greater than 65% of similar tractors.

Technical Specifications

Engine

Manufacturer
SisuDiesel
Model
74CTA
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
24-valve
Fuel Type
Diesel
Induction Type
Turbocharged intercooled
Cylinders
6
Displacement (ci)
449.4
Bore (in)
4.252
Stroke (in)
5.276
Rated RPM
2200
Power Output (hp)
216.2 hp (161.2 kW) at 2000 rpm

Transmission

Type
Selective gear fixed ratio with partial (6) range operator controlled power shift
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
210
Width (in)
79.1
Height (in)
122 (cab)
Operating Weight (lb)
17460

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 4WD
Drive Type
-
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural/Standard (AG)
Manufacture - End Year
-
Hitch Type
Three-Point Hitch (Categories 3/3N)
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
12 volts
Brake Type
-
Hydraulic System Type
Closed center pressure flow compensated (PFC)

Test Results

Nebraska Tractor Test Laboratory - Test Date: April - May, 2007

Maximum Power and Fuel Consumption

  • Maximum Power: 216.2 HP (161.2 kW) at 2000 rpm
  • Fuel Consumption at Maximum Power: 12.40 Gal/hr (46.95 l/h) with a fuel efficiency of 0.408 lb/hp.hr (0.248 kg/kW.h)
  • Fuel Efficiency at Standard PTO Speed (1000 rpm): 17.43 Hp.hr/gal (3.43 kW.h/l)

Drawbar Performance

  • Power at Maximum Drawbar Pull (15th Gear): 167.0 HP (124.5 kW) with a drawbar pull of 9035 lbs (40.2 kN) at a speed of 6.93 mph (11.16 km/h)
  • Fuel Consumption at Maximum Power: 0.501 lb/hp.hr (0.305 kg/kW.h) with a fuel efficiency of 14.16 Hp.hr/gal (2.79 kW.h/l)

Torque and Engine Performance

  • Maximum Torque: 651.8 lb-ft (883.8 Nm) at 1450 rpm
  • Torque Rise: 43.8% with a torque rise of 35% at 1760 rpm

Hydraulic Performance

  • Maximum Force Exerted: 14545 lbs (64.7 kN) at hitch points
  • Pump Delivery Rate: 30.8 GPM (116.6 l/min) at minimum pressure and rated engine speed
  • Hydraulic Power at Maximum Pressure: 34.9 HP (26.0 kW) at delivery pressure of 2815 psi (194 bar)

Overall Efficiency

  • Fuel Efficiency at Rated Engine Speed (2200 rpm): 16.24 Hp.hr/gal (3.20 kW.h/l)
  • Fuel Consumption: 11.69 Gal/hr (44.26 l/h) at 2200 rpm



Nebraska Tractor Test Lab.(2007).Nebraska Summary: S599 AGCO RT180A Diesel. Lincoln, NE:Nebraska Tractor Test Laboratory. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/2931
