AGCO LT85A

Last Updated: July 2024

Overview

The AGCO LT85A is a versatile utility tractor available in both 2WD and Front Wheel Assist configurations. It features a Sisu Diesel 44CTA engine, producing up to 110.1 hp at PTO. The tractor has a 16-speed partial power shift transmission and is equipped with a robust hydraulic system. It offers various configurations for different agricultural needs, including options for open and closed center hydraulic systems.

Key Specifications

Category: Utility

Power Output: 110.1

Transmission: Partial power shift

Drive Type: 2WD / FWA

Operating Weight: 10605

Fuel Type: Diesel

Image Gallery

AGCO LT85A Tractor

AGCO LT85A vs. Similar Tractors

Power Output

Above Average

Greater than 74% of similar tractors.

Hitch Capacity

Above Average

Greater than 83% of similar tractors.

Operating Weight

Average

Greater than 60% of similar tractors.

Technical Specifications

Engine

Manufacturer: Sisu Diesel
Model: 44CTA
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: 16-valve
Fuel Type: Diesel
Induction Type: Turbocharged intercooled
Cylinders: 4
Displacement (ci): 268
Bore (in): 4.252
Stroke (in): 4.724
Rated RPM: 2200
Power Output (hp): 110.1

Transmission

Type: Partial power shift
Forward Gears: 16
Reverse Gears: 16
Total Gears: -

Dimensions

Length (in): 172
Width (in): 79.3
Height (in): 109
Operating Weight (lb): 10605

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD / Front Wheel Assist (FWA)
Drive Type: 2WD / FWA
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): 15
Front Tire Width (in): -
Rear Tire Diameter (in): 30
Rear Tire Width (in): 18.4
Front/Rear Rim Diameter (in): -
Tire Type: Standard tires (ag) for 2WD and 4WD specified; various optional sizes provided
Manufacture - End Year: -
Hitch Type: Category II three-point hitch
Hitch Category: -
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: ROPS (Foldable) and Cab available
Starter Type: Electric
Brake Type: -
Hydraulic System Type: Open center and Closed center options available
