Agco GT45A

Last Updated: June 2024

Overview

The Agco GT45A is a utility tractor that is suitable for a variety of tasks around the farm. It is powered by a 3-cylinder engine with a natural induction system, producing 52 horsepower at a rated RPM of 2200. The engine's displacement is 183.1 cubic inches. This tractor is equipped with a synchro-shuttle transmission system, offering a substantial number of gear options with 20 forward gears and 10 reverse gears. With an operating weight of 5820.3 lbs and a lift capacity of 3520 lbs at the three-point hitch, the GT45A can handle heavy-duty operations. The turning radius of 12.2 ft makes it quite maneuverable in tight spaces. Additional features of this tractor include two remote control valves and a pump flow capacity of 22.8 gallons per minute, enhancing its capability to work with various implements. Though the tractor's tire dimensions and specific drivetrain details are not specified, this model appears to have features that support both comfort and performance, with the availability of both a cab and ROPS/FOPS for operator safety.
Show more...

Key Specifications

Category: Utility

Power Output: 52

Transmission: Syncro-Shuttle

Operating Weight: 5820.3

Lift Capacity: 3520

Agco GT45A vs. Similar Tractors

Power Output
Average
Greater than 50% of similar tractors.
Hitch Capacity
Average
Greater than 64% of similar tractors.
Operating Weight
Average
Greater than 47% of similar tractors.

Technical Specifications

Engine

Manufacturer
-
Model
-
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
Natural
Cylinders
3
Displacement (ci)
183.1
Bore (in)
-
Stroke (in)
-
Rated RPM
2200
Power Output (hp)
52

Transmission

Type
Syncro-Shuttle
Forward Gears
20
Reverse Gears
10
Total Gears
-

Dimensions

Length (in)
146.4
Width (in)
70.8
Height (in)
104 (conversion from ft, top of cab height used)
Operating Weight (lb)
5820.3

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category II, Three-Point Hitch (best guess based on "Cat II")
Hitch Category
Category II
Hitch Position
Rear
Hitch Capacity (lb)
3520
Operator Station Type
Both Cab and ROPS/FOPS available
Starter Type
-
Brake Type
-
Hydraulic System Type
-
